Name: Switch Industrial Ethernet 8 ports
Brand: Indu-Sol
SKU: 114110502
Price: 414.0 EUR
Availability: InStock

Revolution PI

Switch Industrial Ethernet 8 ports

Home/Store/Industrial Ethenet Switch PROmesh

Product Details

Marque: Indu-Sol

VAT: VAT not included

Estimated delivery time: 3 to 5 working days upon receipt of payment.

Manufacturer's warranty: Manufacturer's warranty

PROmesh B8: The Reliable Managed Switch for Industrial Ethernet Networks

The PROmesh B8 is a managed switch with 8 RJ45 ports designed for use in PROFINET and EtherNet/IP networks. It features a 6.3 Gbps backplane capacity and international certifications.

Product Highlights

8 RJ45 ports, optimized for PROFINET and EtherNet/IP
6.3 Gbps backplane capacity
International approvals (UL, CSA, CE, UKCA)
Easy integration with support for E-Plan, GSDML, EDS

The PROmesh B8 is specifically designed for the requirements of industrial environments and supports both PROFINET and EtherNet/IP. With 8 RJ45 ports, the PROmesh B8 allows for flexible network configuration. The 6.3 Gbps backplane capacity of the PROmesh B8 ensures smooth data transmission

Support for design data engineering, including E-Plan, Step, GSDML, and EDS, simplifies integration and configuration into existing systems.

Features:

Designed for industrial applications with a focus on reliability and performance
Supports data rates up to 100 Mbps
Basic diagnostic features make maintenance and troubleshooting easy
User-friendly configuration via web interface

Ports	8 x 100 Mbit/s RJ45
PROFINET Standard	CC-B according to V2.4
Monitoring	24 V, Temperature, Port Statistics, Network Load
Netload Class	III
Redundancy	MRP, RSTP
Protection Rating	IP 20
Dimensions (H x W x D in mm)	138 x 53 x 110
Firewall	x
Routing	x
Mounting Type	DIN rail
Backplane	6.3 Gbps
Throughput	1.6 Mpps
Shared Buffer	2 Mbit
Certifications	UL/CSA CE UK CA
