Revolution PI by Kunbus RevPI Connect 5 32Go 8Go + WIFI + 1xCAN FD

Equipped with the Raspberry Pi Compute Module 5, which combines the powerful ARM Cortex-A76 processor and the versatile Broadcom BCM2712 system-on-chip, the RevPi Connect 5 enables energy-efficient processing with extensive peripheral connectivity - perfect for industrial automation based on proven Raspberry Pi technology.

The quad-core processor clocks at up to 2.4 GHz and therefore offers significantly higher computing power compared to the Compute Module 4.

For high connectivity, the RevPi Connect 5 can be equipped with various communication interfaces: from wireless WLAN and industry-proven RS485 to the fast CAN FD bus.

The modular approach of the RevPi Connect 5 enables flexible expansion with RevPi I/O modules for additional inputs and outputs as well as RevPi gateway modules for connecting additional fieldbus protocols. A total of up to ten expansion modules (including a maximum of two gateways) can be attached to the RevPi Connect 5. Hardware function watchdog. The device has one CAN FD port and has WLAN or Bluetooth connectivity. In addition to the integrated antenna of the compute module, an external antenna can be connected via an SMA socket for optimal reception.
